The Packaging Designer's Book of Patterns

The essential packaging design resource, now with more patterns than ever!

For more than two decades, The Packaging Designer's Book of Patterns has served as an indispensable source of ideas and practical solutions for a wide range of packaging design challenges.

This Fourth Edition offers more than 600 patterns and structural designs—more than any other book—all drawn to scale and ready to be traced, scanned, or photocopied. Online access to the patterns in digital format allows readers to immediately use any pattern in the most common software programs, including Adobe Photoshop and Illustrator. Every pattern has been test-constructed to verify dimensional accuracy. The patterns can be scaled to suit particular specifications—many are easily converted to alternate uses—and most details are easily customizable. Features of this Fourth Edition include:

• More than 55 new patterns added to this edition—over 600 patterns in all
• A broad array of patterns for folding cartons, trays, tubes, sleeves, wraps, folders, rigid boxes, corrugated containers, and point-of-purchase displays
• Proven, scalable patterns that save hours of research and trial-and-error design
• Packaging patterns that are based on the use of 100% recyclable materials
• Includes access to a password protected website that contains all 600+ patterns in digital form for immediate use

Comprehensive and up to date, The Packaging Designer's Book of Patterns, Fourth Edition enables packaging, display, and graphic designers and students to achieve project-specific design objectives with precision and confidence.

Preface to the Fourth Edition iv

Foreword v

1. Introduction 1

2. The Folding Carton 19

Trays 25

Tubes 99

Sleeves, Wraps, and Folders 291

3. The Set-Up or Rigid Paper Box 421

4. Corrugated Containers 461

5. Point-of-Purchase Displays 589

Glossary 687

Bibliography 690

Index 691

Now retired, GEORGE L. WYBENGA was professor in the Packaging Design Program at the Fashion Institute of Technology and succeeded Lászlo Roth as chairperson. He remains active as a consultant to the packaging industry.

The late LÁSZLO ROTH was chairperson of the Packaging Design Program at the Fashion Institute of Technology in New York.
