Electricity from Sunlight

Electricity from Sunlight: Photovoltaics Systems Integration and Sustainability, Second Edition is an essential primer for new entrants to the PV industry, needing a basic appreciation of complete PV systems, and to students on undergraduate and graduate courses on renewable energy and photovoltaics. It also offers a unique treatise of the sustainability of emerging transformative technologies, which makes it useful to both system analysts and energy policy strategists.

Co-author, Vasilis Fthenakis, is Recipient of the 2018 William R. Cherry Award

The Cherry Award recognizes an individual engineer or scientist who has made a significant contribution to the advancement of the science and technology of photovoltaic energy conversion, with dissemination by substantial publications and presentations. Fthenakis was honored for his pioneering research at the interface of energy and the environment that catalyzed photovoltaic technology advancement and deployment world-wide.Electricity from Sunlight, hochgelobt für seine ansprechende Gestaltung, seinen verständlichen Stil und seine klaren Erklärungen komplexer Sachverhalte ohne viel Mathematik, wurde gründlich überarbeitet und aktualisiert. Das Buch beschreibt die Fortschritte auf dem weltweiten Photovoltaik-Markt, bei der Wirtschaftlichkeit und Installationsbasis.

Kernaspekte der 2. Auflage:
- Aktuelles zu den Fortschritten der Photovoltaik, relevantes neues Material zu netzgekoppelten Systemen.
- Noch detailliertere Erläuterung der wissenschaftlichen Prinzipien der Photovoltaik, von Solarzellen, Modulen und Systemen.
- Aktuelle Informationen aus dem Photovoltaik-Markt, inkl. Umwandlungseffizienz und Ausbau netzfreundlicher Kraftwerke.
- Fragen am Ende der Kapitel unterstützen Dozenten und Studenten durch Anleitungen zum Selbststudium.
- Neue Kapitel zu Fertigungsprozessen, Materialien und der Verfügbarkeit sonstiger Ressourcen.
- Neuer Abschnitt zu Photovoltaik-Großanlagen mit Informationen zur Ausweitung der globalen Kapazität, zu Photovolatik-Großanlagen und erschwinglichen Lösungen zur Bewältigung fluktuierenden Einspeisung von Energie.
- Systemanalyse neuer Anwendungen im Bereich günstiger Photovoltaik-Anlagen wie bei der Energiespeicherung und Wasserentsalzung.
- Erheblich umfangreicher Abschnitt zu Wirtschaftlichkeit und Umweltaspekten mit Erläuterungen zu den Energiekosten im Vergleich zu den Investitionskosten, ROI und Lebenszyklusanalyse.

Die 2. Auflage von Electricity from Sunlight: Photovoltaics Systems Integration and Sustainability ist eine Einführung in die Photovoltaik, richtet sich an Einsteiger, die die Grundlagen von kompletten Photovoltaiksystemen verstehen möchten, sowie an Studenten im Grund- und Hauptstudium in Kursen zu erneuerbarer Energie und Photovoltaik. Es behandelt in einzigartiger Weise die Nachhaltigkeit neuer umwälzender Technologien und ist sowohl für Systemanalysten als auch Strategen in der Energiepolitik gut geeignet.
