Coplanar Waveguide Circuits, Components, and Systems

Up-to-date coverage of the analysis and applications of coplanar waveguides to microwave circuits and antennas

The unique feature of coplanar waveguides, as opposed to more conventional waveguides, is their uniplanar construction, in which all of the conductors are aligned on the same side of the substrate. This feature simplifies manufacturing and allows faster and less expensive characterization using on-wafer techniques.

Coplanar Waveguide Circuits, Components, and Systems is an engineer's complete resource, collecting all of the available data on the subject. Rainee Simons thoroughly discusses propagation parameters for conventional coplanar waveguides and includes valuable details such as the derivation of the fundamental equations, physical explanations, and numerical examples.

Coverage also includes:

• Discontinuities and circuit elements
• Transitions to other transmission media
• Directional couplers, hybrids, and magic T
• Microelectromechanical systems based switches and phase shifters
• Tunable devices using ferroelectric materials
• Photonic bandgap structures
• Printed circuit antennas

Das erste Buch, das sich ausschließlich theoretischen und anwendungstechnischen Fragen koplanarer Wellenleiter widmet! Immer wichtiger werden solche Leiter als Alternative zu herkömmlichen Stripline-Wellenleitersystemen. Hier erfahren Sie alle interessanten Details von einem ausgewiesenen Experten auf diesem Gebiet. Preface.

Introduction.

Conventional Coplanar Waveguide.

Conductor-Backed Coplanar Waveguide.

Coplanar Waveguide with Finite-Width Ground Planes.

Coplanar Waveguide Suspended Inside A Conducting Enclosure.

Coplanar Striplines.

Microshield Lines and Coupled Coplanar Waveguide.

Attenuation Characteristics of Conventional, Micromachined, and Superconducting Coplanar Waveguides.

Coplanar Waveguide Discontinuities and Circuit Elements.

Coplanar Waveguide Transitions.

Directional Couplers, Hybrids, and Magic-Ts.

Coplanar Waveguide Applications.

References.

Index. "A resource for engineers, collecting all available data on the subject of coplanar waveguide circuits, components, and systems." (SciTech Book News Vol. 25, No. 2 June 2001) RAINEE N. SIMONS, PhD, works in the Communications Technology Division at the National Aeronautics and Space Administration's Glenn Research Center in Cleveland, Ohio, and is a fellow of IEEE. Up-to-date coverage of the analysis and applications of coplanar waveguides to microwave circuits and antennas

The unique feature of coplanar waveguides, as opposed to more conventional waveguides, is their uniplanar construction, in which all of the conductors are aligned on the same side of the substrate. This feature simplifies manufacturing and allows faster and less expensive characterization using on-wafer techniques.

Coplanar Waveguide Circuits, Components, and Systems is an engineer's complete resource, collecting all of the available data on the subject. Rainee Simons thoroughly discusses propagation parameters for conventional coplanar waveguides and includes valuable details such as the derivation of the fundamental equations, physical explanations, and numerical examples. Coverage also includes:
* Discontinuities and circuit elements
* Transitions to other transmission media
* Directional couplers, hybrids, and magic T
* Microelectromechanical systems based switches and phase shifters
* Tunable devices using ferroelectric materials
* Photonic bandgap structures
* Printed circuit antennas
